PlantUML Primer

1. Purpose and Philosophy

PlantUML was created to solve a fundamental problem: visual diagrams in traditional tools (Visio, draw.io) don’t version control well and drift from code. By describing diagrams as text, PlantUML treats diagrams like code—diffable, mergeable, and automatically renderable.

Strengths:

  • Version control friendly: Plain text files in Git show meaningful diffs
  • Consistency: Automatic layout ensures uniform styling across diagrams
  • Integration: Renders in CI/CD, documentation sites, IDEs, and wikis
  • Expressiveness: Supports UML (class, sequence, component), C4 models, Gantt charts, mind maps, and more
  • Toolchain independence: Render via CLI, web service, or IDE plugins

Limitations:

  • Layout control: Automatic layout sometimes produces suboptimal arrangements
  • Learning curve: Syntax is terse; advanced features require documentation lookups
  • Rendering dependencies: Requires Java runtime and Graphviz for some diagram types
  • Visual tweaking: Fine-grained positioning and styling is limited compared to WYSIWYG tools

Use PlantUML for:

  • Architecture diagrams in documentation (C4 models, component diagrams)
  • Sequence diagrams for interaction flows
  • Class diagrams for domain modeling
  • Deployment and infrastructure diagrams
  • Any diagram that should evolve with code

Avoid PlantUML for:

  • High-fidelity mockups or pixel-perfect layouts
  • Diagrams requiring frequent visual iteration (use draw.io for drafts, then migrate to PlantUML)
  • Presentations where manual layout control is critical

Authoritative References:

2. Getting Started

To begin creating PlantUML diagrams, you need a text editor and a way to render the diagrams. The quickest path is using an online editor or IDE plugin.

Quickest start (no installation):

  1. Visit PlantUML Online Server
  2. Write your diagram syntax in the text area
  3. See the rendered diagram update in real-time
  4. Export to PNG or SVG when satisfied

Recommended local setup:

Option A: VS Code (cross-platform):

  1. Install VS Code
  2. Install the PlantUML extension
  3. Create a file with .puml extension
  4. Press Alt+D to preview the diagram
  5. The extension handles rendering automatically (uses online server by default)

Option B: Command-line with Java:

  1. Install Java Runtime (JRE 8 or later)
    • macOS: brew install openjdk
    • Ubuntu/Debian: sudo apt-get install default-jre
    • Windows: Download from java.com
  2. Install PlantUML
    • macOS: brew install plantuml
    • Ubuntu/Debian: sudo apt-get install plantuml
    • Windows: Download JAR from plantuml.com/download
  3. Install Graphviz (required for some diagram types)
    • macOS: brew install graphviz
    • Ubuntu/Debian: sudo apt-get install graphviz
    • Windows: Download from graphviz.org
  4. Render a diagram: plantuml diagram.puml

For IntelliJ IDEA users:

Once set up, create a simple sequence diagram to verify everything works:

@startuml
Alice -> Bob: Hello
Bob --> Alice: Hi there!
@enduml

Save this as test.puml and render it to confirm your environment is ready.

3. Core Syntax

Minimal cheatsheet:

Sequence Diagram

@startuml
actor User
participant "Web UI" as UI
participant "API" as API
database "Database" as DB

User -> UI: Request page
UI -> API: GET /tasks
API -> DB: SELECT * FROM tasks
DB --> API: Task list
API --> UI: JSON response
UI --> User: Rendered page
@enduml

Component Diagram

@startuml
package "Presentation Layer" {
  [Web UI]
  [REST API]
}

package "Business Logic" {
  [Task Service]
  [Workflow Engine]
}

database "PostgreSQL" {
  [Tasks Table]
}

[Web UI] --> [REST API]
[REST API] --> [Task Service]
[Task Service] --> [Workflow Engine]
[Task Service] --> [Tasks Table]
@enduml

Class Diagram

@startuml
class Task {
  - id: UUID
  - name: String
  - status: Status
  + complete(): void
  + isPending(): boolean
}

enum Status {
  PENDING
  IN_PROGRESS
  COMPLETED
}

Task --> Status
@enduml

Deployment Diagram

@startuml
node "Web Server" {
  [Nginx]
}

node "Application Server" {
  [Spring Boot App]
}

node "Database Server" {
  database "PostgreSQL"
}

[Nginx] --> [Spring Boot App]: reverse proxy
[Spring Boot App] --> [PostgreSQL]: JDBC
@enduml

C4 Context Diagram

@startuml
!include https://raw.githubusercontent.com/plantuml-stdlib/C4-PlantUML/master/C4_Context.puml

Person(user, "User", "Task manager user")
System(taskSystem, "Task Management System", "Manages user tasks")
System_Ext(emailSystem, "Email System", "Sends notifications")

Rel(user, taskSystem, "Uses")
Rel(taskSystem, emailSystem, "Sends emails via")
@enduml

4. Patterns and Idioms

Documentation Structure

Organize diagrams alongside code or in dedicated directories:

project/
├── docs/
│   ├── architecture/
│   │   ├── context.puml          # C4 context diagram
│   │   ├── containers.puml       # C4 container diagram
│   │   └── components.puml       # Component details
│   ├── sequences/
│   │   ├── user-login.puml
│   │   └── task-workflow.puml
│   └── domain/
│       └── task-model.puml       # Class diagram
├── src/
└── README.md

Common Styling Patterns

@startuml
' Custom styling for consistent look
skinparam shadowing false
skinparam linetype ortho
skinparam rectangle {
    BackgroundColor LightBlue
    BorderColor DarkBlue
}

rectangle "Component A" as A
rectangle "Component B" as B

A --> B
@enduml

Including Shared Definitions

@startuml
' common-styles.iuml
!define COMPONENT_COLOR #LightBlue
!define DATABASE_COLOR #LightGreen
@enduml
@startuml
!include common-styles.iuml

rectangle "Service" COMPONENT_COLOR
database "DB" DATABASE_COLOR
@enduml

Embedding Notes and Documentation

@startuml
class Task {
  + complete()
}

note right of Task
  Tasks transition from PENDING
  to COMPLETED via complete()
  method. Status changes are
  immutable.
end note

5. Tooling and Rendering

PlantUML offers multiple rendering approaches, from command-line tools for batch processing to IDE integrations for interactive development. Choose the setup that best fits your workflow.

Command-Line Rendering

The command-line interface is ideal for automation, batch processing, and CI/CD pipelines.

# Install PlantUML (requires Java)
# macOS:
brew install plantuml

# Ubuntu/Debian:
sudo apt-get install plantuml

# Windows:
# Download from https://plantuml.com/download

# Render diagram to PNG
plantuml diagram.puml

# Render to SVG (vector, preferred for web)
plantuml -tsvg diagram.puml

# Render all .puml files in directory
plantuml src/diagrams/*.puml

# Watch for changes and auto-render
plantuml -gui src/diagrams/

IDE Integration

IDE plugins provide live previews, making it easy to iterate on diagrams while writing code or documentation.

Online Editors

For quick experimentation without installing anything, online editors render diagrams in your browser.

Rendering Services

You can embed diagrams dynamically in documentation by referencing source files through PlantUML’s public rendering service.

Embed in Markdown (GitHub, GitLab):
![Diagram](http://www.plantuml.com/plantuml/proxy?src=https://raw.githubusercontent.com/user/repo/main/diagram.puml)

Build Integration

Automate diagram rendering in continuous integration pipelines to keep visuals in sync with code changes.

# GitHub Actions: Render PlantUML in CI
name: Render Diagrams
on: [push]
jobs:
  render:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3
      - name: Render PlantUML
        uses: grassedge/generate-plantuml-action@v1.5
        with:
          path: docs/diagrams
          message: "Auto-generated diagrams"

6. Integration

PlantUML integrates naturally into documentation workflows, version control systems, and static site generators, treating diagrams as code artifacts.

Hugo/Jekyll Static Sites

# Pre-render diagrams in build pipeline
#!/bin/bash
for file in src/images/*.puml; do
  plantuml -tsvg "$file" -o ../../static/images/
done
# Reference in markdown
![Architecture Diagram](images/architecture.svg)

Documentation as Code

Keep diagrams next to code they document:

project/
├── src/
│   ├── domain/
│   │   ├── task.py
│   │   └── task-model.puml      # Domain model diagram
│   └── api/
│       ├── routes.py
│       └── api-sequence.puml    # API interaction diagram

Version Control Workflow

# Edit diagram
vim docs/architecture.puml

# Render locally to verify
plantuml -tsvg docs/architecture.puml

# Commit both source and rendered (or generate in CI)
git add docs/architecture.puml static/images/architecture.svg
git commit -m "Update architecture diagram"

Automated Diagram Updates

# Makefile for diagram rendering
DIAGRAMS := $(wildcard docs/**/*.puml)
SVGS := $(DIAGRAMS:.puml=.svg)

all: $(SVGS)

%.svg: %.puml
	plantuml -tsvg $<

clean:
	rm -f $(SVGS)

.PHONY: all clean

7. Accessibility and Review

Accessibility Practices

  • Alt text in markdown: Provide meaningful descriptions when embedding diagrams
    ![Sequence diagram showing user login flow with authentication service](diagrams/login-sequence.svg)

  • SVG output preferred: Vector graphics scale without quality loss
  • High contrast: Use skinparam monochrome true for black-and-white rendering
  • Descriptive labels: Avoid abbreviations; spell out component names

Review and Versioning

  • Text diffs are readable: Reviewers can see diagram changes in Git diffs
  • Comments in diagrams: Use ' single quote for inline comments
    @startuml
    ' This diagram shows the authentication flow
    ' Updated 2024-01-15 to reflect OAuth integration

    actor User
    participant "Auth Service" as Auth

    User -> Auth: Login request
    @enduml

  • Version markers in diagrams:
    @startuml
    title User Authentication Flow\n(Version 2.0 - OAuth Integrated)
    ...
    @enduml


Common Pitfalls

  • Graphviz dependency: Some diagrams require Graphviz; install with PlantUML
  • Large diagrams become unreadable: Break into multiple smaller diagrams
  • Layout quirks: Use skinparam linetype ortho for cleaner orthogonal lines
  • Color accessibility: Avoid red-green combinations; test with colorblind simulators
  • Over-detailing: Keep diagrams high-level; excessive detail obscures intent

8. Example and Reference

Complete working example: Three-Layer Architecture

@startuml
' File: architecture-layers.puml
' Three-Layer Architecture diagram for task management system

skinparam shadowing false
skinparam linetype ortho
skinparam componentStyle rectangle

title Three-Layer Architecture\nTask Management System

package "Presentation Layer" as PL {
  component "Web UI" as WebUI
  component "REST API" as API
}

package "Business Logic Layer" as BLL {
  component "Task Service" as TaskSvc
  component "User Service" as UserSvc
  component "Notification Service" as NotifSvc
}

package "Data Access Layer" as DAL {
  component "Task Repository" as TaskRepo
  component "User Repository" as UserRepo
  database "PostgreSQL" as DB
}

' Dependencies
WebUI --> API
API --> TaskSvc
API --> UserSvc
TaskSvc --> NotifSvc
TaskSvc --> TaskRepo
UserSvc --> UserRepo
TaskRepo --> DB
UserRepo --> DB

' Notes
note right of PL
  Handles HTTP requests,
  input validation,
  session management
end note

note right of BLL
  Domain logic,
  business rules,
  workflow orchestration
end note

note right of DAL
  Persistence operations,
  query optimization,
  transaction management
end note

@enduml

Render:

plantuml -tsvg architecture-layers.puml

Embed in documentation:

# System Architecture

Our system uses a three-layer architecture to separate concerns:

![Three-layer architecture diagram](images/architecture-layers.svg)

Each layer has clear responsibilities and dependencies flow downward only.

Applying custom styling to the example:
